MIL-PRF-62540A(AT)
3.3.1 Weight. The weight of the harness and cable assemblies shall not exceed the weight
specified on the applicable drawing (see 4.6.2 and 6.2).
3.3.2 Length. The length of the harness and cable assemblies shall be as shown on the
applicable drawing. Length measurements shall be as indicated in figure 1 (dimensions W, X, Y
and Z) (see 4.6.2).
3.3.3 Tolerances.
3.3.3.1 Connector and adapter angular tolerances. The angular tolerance between the
connector keyway and centerline of 45 degree ( ) or 90 adapters shall be as specified in table I.
Angular tolerance between the connector keyway and the centerline of the 90 boots shall be
+ 10 (see 4.6.2 and 6.2).
TABLE I. Angular tolerance.
Shell size
Angular tolerance ( )
08
+15
+15
09
+15
10
+15
11
+10
12
+10
13
+10
14
+10
15
+7.5
16
+7.5
17
+7.5
18
+7.5
19
+7.5
20
+5
21
22
+5
23
+5
+5
24
+5
25
+5
28
+5
32
+5
36
+5
40
3.3.3.2 Dimensional tolerance. The dimensional tolerances on length dimensions shall be
as follows (see 4.6.2):
4
