INCH-POUND
MIL-DTL-22442/26E(AS)
5 January 1998
SUPERSEDING
MIL-C-22442/26D(AS)
18 February 1992
DETAIL SPECIFICATION SHEET
CABLE ASSEMBLY, AIRCRAFT AUDIO, CX-l 3126A/A
This specification sheet is approved for use by the Naval Air Systems Command,
Department of the Navy, and is available for use by all Departments and Agencies of the
Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-DTL-22442 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
* FIGURE 1. Cable assembly P/N M22442/26-1.
AMSC N/A
1 of 5
FSC 5995
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
